Main Technical Parameters
| Machine frame | 12mm thickness steel Plate |
| Main motor | 1.5KW motor,EURA inverter speed control |
| Rear material feeding part | 0.75KW EURA Brand simulation automatic synchronous feeding. |
| Front material feeding part | 3.7KW China brand Servo motor feeding |
| Cutting knife | with transformer heating |
| Copper knife | middle heating tube and both sides of the heating plate double heating |
| The devices in the rear feeding part | Independent storage rack and loading by pneumatic Shutdown for material breakage Splicing device Magnetic powder tension |
| Width of bag making | 150-420mm |
| Length of bag making | 320-650mm |
| Bag making speed | 100--300 100-300pcs/channel/min, 200-600pcs/min/2channels |
| Switch, buttons | DELIXI brand |
| Photocell | Italy brand |
| Rubber roller of the front material feeding | Harbin Bearing |
| Total power | 17KW |
| Overall dimension(L*W*H) | 7000*1800*1900mm7000*1800*1900MM |
| Voltage | 380V, 3Phase, 50Hz |
