Applications:
The machine is new and further improvement model on the basis of advanced technology at home and abroad, it is integrated high-tech product in the field of machine, electricity, gas and light.This machine is suitable for cartoning packaging of pharmaceutical aluminum plate, medicine bottles, oral liquid, plaster, facial mask, cosmetics and all kinds of electronic products, daily necessities, and similar items,the machine can automatically complete manual folding, paper box opening, goods cartoning, batch number printing, sealing and other work.The machine can be used alone, and it also can be connected with other equipment for forming production line.
Features:
■PLC automatic control, variable frequency speed regulation, electrical components are internationally renowned brands.
■Man-machine interface operating system is equipped.
■The overload protection of main drive can automatically display failure cause,cartoning speed and finished product counting.
■Missing, elimination and other function of material and operating manual can be automatically inspected.
■Cartoning could could automatically stop if there is no material or operating manual.
■There is stable performance and simple operation, it is easy to understand
| Model | 80 | 120 |
| Carton speed | 60-120box/min | 40-70box/min |
| Box Dimension range (LxWxH) | (70-180)X(30-80)X(15-50)mm | (70-180)X(70-120)X(15-50)mm |
| Unfolded leaflet specification | (90-170)X(110-210)mm | |
| Fold range | 1-4fold | |
| Working pressure | ≥0.6mpa | |
| Power supply | 380V 50HZ | 380V 50HZ |
| Motor power | 0.75kw | 0.75kw |
| Machine dimension (LxWxH) | 3200X1350X1600mm | 3300X1350X1600mm |
| Machine weight | 1200Kg | 1300Kg |
